Product parameters

Specially designed for astronomical lens

Mobile star searching and free capture

Patrol the sky area and there is no blind area

Easy rotation and stable center of gravity

Gear fine adjustment and turbine self-locking

Material: aluminum alloy

Bearing：5-10kg

Base diameter：61mm

Base interface：UNC 3/8''

Body height：195mm

Weight: ≈ 1.4kg

Tailored for astronomical lenses

*Mobile star searching free capture

*There is no blind area in the patrol area

*Easy rotation and stable center of gravity

*Gear fine tuning turbine self-locking

*Aluminum alloy material is safe and tough

Product parameters

Physical size

Coarse adjustment / fine adjustment

There are two adjustment modes: coarse adjustment, fine adjustment in pitch and horizontal direction

1. Fast coarse adjustment, i.e. follow-up mode

2. Precise turbine fine tuning, i.e. inching mode

Conventional operation of fine adjustment: first use coarse adjustment to quickly adjust the lens to the approximate position, and then use turbine fine adjustment to further accurately locate and track

① Pitch turbine trim handwheel

② 75 ° dovetail plate elastic knob

③ Dovetail quick safety screw

④ 75 ° dovetail groove

⑤ Pitch coarse / fine adjustment switch handle screw

⑥ 360 ° horizontal turbine trim handwheel

⑦ Bottom 3 / 8 standard interface

⑧ Horizontal coarse adjustment / fine adjustment switch handle screw (the direction can be adjusted outward)

Physical application

With D70mm APO telescope

With MEADE D114mm Newton reflection telescope

With D70mm APO telescope

With D90mm Marka telescope

With D80mm BINO Telescope

Detail display

packing

Installation mode

① Elastic knob           ② Safety screw            ③ Handle screw x2            ④ Fine tuning handwheel x2

Installation instructions: unpack the package, first check whether all accessories are complete (accessories are shown in the figure), and then screw the accessories with digital symbols to the position of digital symbols to complete the installation.

Connection with support

① PTZ base interface unc3 / 8 "female thread                             ② Tripod bottom locking screw (unc3 / 8 ")
