CNC rings：
The products are processed by CNC high precision CNC machine tools and milling methods. Finished product error is less than or equal to +0.002mm
All parts are made of block material and processed separately. High precision, no distortion.
Cuttingprofilesrings：
Most Cutting profiles rings made of aluminumextrudedsection.
The aluminum extruded section，lt looks like a long strip of material, its section and scope rings 2D shape are same, Its length is usually several meters or more..
Next is the production process:
Long aluminium is extruded from special machines.In order to facilitate production, the raw material of aluminium is slightly soft, otherwise it will damage the mould and machine.Then, the quality inspectors inspect the aluminium profile and cut it；Subsequently, the worker will cut the profile into sections according to the drawings， next is drilling the screw hole, next is After anodizing, next the rings were finished .The advantage of this product is that it is very cheap. Compared with CNC, it lacks precision processing and costs only one tenth or less of its cost. However, the accuracy of such products is insufficient, the dimension tolerance is about +0.05 mm or +0.2mm; and there are quite a few rings with stress distortion problems.Aluminum extruded section rings also have one drawback: In order to facilitate extrusion processing, the material is soft.
And the ring of CNC process is made of block material. The material can be very hard. There is no need to worry about the processing of the blank, so the material strength of the ring is very high. The error is less than or equal to +0.002mm.
Profiled mount also have one drawback:
In order to facilitate extrusion processing, the material is soft.
And the ring of CNC process is made of block material. The material can be very hard. There is no need to worry about the processing of the blank, so the material strength of the ring is very high. The error is easily less than or equal to +0.002mm.
Working principle ofreverse recoil rings:The cushion spring and cushion block are used to offset the back seat force, and the wear errors of materials are reduced by using "precision guide rail" and "gap compensation".Note: The product has applied for national patent.Features:Reduced weapon recoil around 40-50%.
All parts are processed by CNC.
Grade III Hard Oxidation Process
Machined from aircraft grade aluminum allo
Fits 30mm main tube scope
Centerline Height – 32.7mm
Machined from extruded aluminum alloy T6061-T6
Hard anodized black matte finish
Clamp attachment – one hex nuts withHollowslots
Overall height :56mm(2.2″ )
Overall length 100mm(4″ )
Inner space between the rings 60mm (2.36 inch)
Ring width: 20mm(0.78inch)
Recoil lug:Springs and sliders
Mount weight: 7oz.
Features:
Reduced weapon recoil around 40-50%.
All parts are processed by CNC.
Grade III Hard Oxidation Process
Machined from aircraft grade aluminum alloy
Offset design for better eye relief position
Fits both 30mm and 1inch main tube scopes
Extra ring top with accessory rail
Specifications:
Rail Type: | Picatinny |
Diameter: | 30mm |
Length: | 100mm |
Height: | 56mm(2.2" from the bottom to the middle of the ring). |
Weight : | 210g |
Material: | Aluminum Alloy |
Color: | Matte Black |
Packaging details:
A piece of 30mm Mount Rings
An Allen Wrench
