NOTE:
1.This link has two headphone versions (Gen 6 and Gen 5) to choose.
2.We've marked it out in the options picture (the 5th gen only has FG colors).
3.When you place an order, please confirm by yourself whether you choose the right one!
Z041 Comtac II Headset （5.0）
1. The fifth-generation circuit board is adopted. better price
2. Four-level volume, even the smallest sound can be clearly picked up.
3. No noise reduction mode, easy to fight.
4. Suitable for all Z-TAC series PTT
5.7.0 plug (non-US NATO plug) needs to be matched with our brand PTT
Z041 Comtac II Headset （6.0）
1.With another noise reduction headset, the price is more favorable
2.Using a newly-designed sixth-generation circuit board, its ability to reduce noise and detect external sound is better than ever.
3.With six volume levels, even the smallest of sounds can be picked up clearly.
4.Indoor and outdoor noise reduction modes make it convenient for users to switch between the two when in different places and environments.
5.Suitable for all Z-TAC series PTT
6.7.0 plugs (non-US Nato Plug) need to be matched with our brand PTT
Using a newly-designed sixth-generation circuit board, its ability to reduce noise and detect external sound is better than ever.
With six volume levels, even the smallest of sounds can be picked up clearly.
Indoor and outdoor noise reduction modes make it convenient for users to switch between the two when in different places and environments.
Z041 Comtac II Headset （5.0）
Z041 Comtac II Headset （6.0）
If you need a plastic box,
Please contact customer service to pay an additional fee to place an order
*Getting Started
1.Hold the (-) key for 1.6 seconds and wait for the on/off tone.
2.To increase volume, press the (+) key.
3.To decrease volume, press the (-) key.
*Instructions
1.Turning On/Off
Hold the (-) key for 1.6 seconds and wait for the on/off tone. If the battery is removed for more than 5 seconds and placed back into the battery slots, the unit resets itself and it will begin at volume level 1. (In the condition of not removing the battery and the battery still has power) When turning on, the unit will automatically go back to the most recent volume level set before the unit was turned off and a tone will sound, corresponding to the current volume level.
2.Volume Up +/Volume Down -
Six levels, each with its own corresponding tone. From the lowest to the highest level: Do, Re, Mi, Fa, So, La. Two “Beeps” will sound when it has reached either the highest or the lowest volume level.
3.Noise Reduction Mode
When powered, unit defaults at Outdoor Mode. Hold (+) key for 1.6 seconds, wait for the tone. “Ding-Dong” means that the unit is in Outdoor Mode, “Ding-Ding-Dong” means that the unit is in Indoor Mode. (In the condition of not removing the battery and the battery still has power) After turning on the unit, it will default to the last mode before its last time powered down.
4.2 Hour Shutdown Timer
Timer begins after the last command given while unit was turned on (unit turned on without any commands). After 2 hours, a triple “Di” will sound, and unit will automatically shut off if no new command is given within 1 minute. However, if there is a new command given within that minute (press (+) or (-) key), the corresponding volume level tone will sound and the 2-hour timer will reset itself.
5.Low Battery Warning
When the battery voltage is under 2.0V, a triple “Beep” alarm will sound. Alarm will sound once every 30 seconds; unit will shut down itself after 6 consecutive alarms.
6.Noise Reduction Mode Recovery Time
1.Outdoor Mode: Noise Reduction Mode activates when it detects harmful levels of noise; it will reset after 1 second.
2.Indoor Mode: Noise Reduction Mode activates when it detects harmful levels of noise; it will reset after 3 seconds.
