RS2 Infrared Thermal Imaging Tactical Night Riflescope Optical Sight for Hunting Shooting Imaging Long Rang IR Rifle Scope WIFI
Set a Cross Partition
Press and hold "Electronic zoom" and "Color standard" for 3 seconds at the same time to open the function of cross setting.
1. Short press "enlarge" or "pictures" choose the cross partition style, Short press the "color code" key to confirm,
2. Short press the "zoom in" or "camera" button to adjust the cross partition (X/Y) position, Short press the "color code" key to confirm,
3. Short press the "zoom in" or "pictures" key position calibration, After the completion of the short press "color code" button to confirm,
4. Long press "color code" button to save and exit.
-RS2 Thermal Imaging Camera
-Observing and sighting thermal imaging scope for hunting
-Entry-level RS2
-384x288 pixels
-WIFI transmission , mobile phone App browsing
Focusing
After the device is turned on and the image is displayed, adjust the lens focus wheel to adjust the image clear (clear target outline)
Charger / Data TYPE-C Interface
★When charging, unscrew the charging interface cover and insert the Type-C charging connector (charging time is about 3~4 hours, charging voltage DC5V)
★Unscrew the charging port cover, connect to the computer, and copy the photo and video data files
Warning Noted
★Because the uncooled infrared telescope uses a very sensitive thermal sensor, it is not allowed to directly aim the lens at a strong radiation source (such as the sun, direct laser beam or reflection, etc.) under any circumstances (turn on or off), otherwise it will Permanent damage to the refrigerated infrared telescope!
★Please check the power when the instrument is used for the first time, charge it before use if necessary, and place the instrument at room temperature during USB charging.
★Do not open the case or modify it without authorization. Maintenance can only be carried out by authorized personnel of our company.
Feature
· 384x 288 pixels Detector
· Support functions of image WIFI transmission, built-in video and photo recording.
· HD 1280x 960 resolution display.
· Working hours are longer than 7 hours.
· Standard diameter of sighting scopes, can be equipped with universal fixture, suitable for use in many rifles
Description
·[21mm standard rail] The 21mm standard rail can be used for most types of rifles or air guns.
·[Clear picture] 384X288@17μm detector, clear image, easier to find hunting targets.
·[Function] WIFI transmission, video recording and photo taking, IPX6 waterproof and anti-fall
·[Good service]One year warranty, if there is any quality problem, we will repair the product for you free of charge.
·[Fast Shipping]24 hours after payment, about 2-7 days from local, about 10-25 days from China.
Specification
Item：RS225-384 / RS25-240
Detector
Type：Uncooled FPA
Pixel：384×288 / 240×180
Spectral range：17μm
NETD：≤60mk@25℃
Focal length：25mm
FOV：15°*11.2°(±5%) / 9.4°*7.0°(±5%)
Frame rate：50HZ
Focus：Manual
Display
Monitor：AMOLED(390*390)
Eyeshield rubber ring：Yes
Operation
Brightness/gain：Automatic/ Manual
Polarity transformation：Black hot/White hot
Digital zoom：1.0--4.0Xcontinuous zoom
Hot pot tracking：Yes
Crosshair：Yes
WIFI：Yes
Storage
Built in：32G
Type：Photography and video recording
Power
Battery：Rechargeable
Working：>5 hours
Environment
Operation：-20℃~50℃
Storage：-40℃~70℃
Physical
Shell color：Black
Interfacce：Equipped with universal fixture
IP ratings：IP66
Dimension：<250*60*60mm
Weight：700g
Interface
Type-C：Yes(charging and data copy)
