The Night Vision Goggle Mount is a precision-machined, highly adjustable, modular mount. It provides an extremely stableplatform for attaching almost every type of night vision goggle used by the Department of Defense and Law Enforcementcommunities. As its name implies, it is an extremely low-profile NVG mount. It is designed to the be lowest possible profile ofany removable NVG mount on themarket in both the active and stowed positions. This geometry is very beneficial in the fieldas it presents a reduced snag hazard.
Like the other mounts in NRT'Hyper Series,itsfeatures a fully modular interface system. Users can change mount interfacesbetween dovetail (included) and bayonet horn (sold separately) without tools, in the field.The horn interface is compatible withthe AN/PVS-7B, AN/PVS-7D, AN/PVS-14. The dovetail interface is compatible with the AN/PVS-15, AN/PVS-18, AN/PVS-31, BNVD-G, TNV/Sentinel. Interfaces areeasily swapped without tools by manipulating a spring-loaded capture pin and sliding them offthe adjustment rail. Vertical adjustment is accomplished with ease by rotating a locking lever on top of the mountbeforesliding the mount up and down the vertical rail. When the desired height is found, the lever is locked down.
Its features a Force-to-Overcome mechanism. When the user wants to stow the goggle, he simply pushes if upwards toovercome the detent. To reengage the goggle, the user simply pulls it down. Thisgross-motion mechanism is the simplest wayto use a night vision mount.
It also features a breakaway system for use during high-intensity activities where a night vision goggle could impact an outsidesurface and become damaged. A shuttle switch allows the user to set the mountto either locked or breakaway mode. Whenlocked, the mount will not will come loose from the shroud without pushing the release button. In breakaway mode, themount will release from the shroud under auser-specified amount of force. This is extremely useful during activities where theNVG and mount can become snagged on other gear or surfaces. Smacking a stowed NVG on a surface during activitiessuch asfast rope and vehicle dismount can snap the user’s head back and severely injure his/her neck. It can also cause damage tothe mounted NVG. But, if the mount has a breakaway system like theHyper Series, it will pop loose from the shroud.Assuming the goggle is dummy-corded to the helmet, the user will have retain it while saving his neck. The Hyper SeriesBreak-Away mode is user-adjustable.A top-mounted set screw allows operators to determine how many foot/pounds pressureare required to pop the mount loose.
Features:
-Vertical, Tilt, and Fore/Aft Adjustment Levers allow for a custom fit user experience
-Helmet Mount Release Button allows one-handed release from helmet bracket or shroud
-Break-Away Button allows user to set the desired mode for mount (break-away or locked), depending on user’s operational needs.
-Glide-Rite infinitely adjustable in both vertical and horizontal directions.
-Reduced weight and an enhanced NVG center of gravity in stow position.
-Auto shut-off integral with each adapter.
MATERIAL:Aerospace Grade Aluminum Alloy, Hard Anodized
VERTICAL ADJUST:1.10″Total Travel
FINITE TILT:23º
FORE/AFT TRAVEL:1.50″Total Travel
AUTO SHUT-OFF:Yes
COMPATIBLE:All Standard Bracket NVG Shrouds
ACCOMMODATES:AN/PVS-7A, AN/PVS-7C, AN/PVS-7B, AN/PVS-7D, AN/PVS-14, AN/PVS-15, AN/PVS-18, AN/PVS-21, BNVD-G, TNV/Sentinel
