PVS-31 Battery Case With Function TB1401

Specification

Color : Multicam( MC), Black( BK), DE ,AOR1

Material: Nylon

Product characteristics

1)100% Brand new and high quality.

2)Use the 4-pin core air connector point-to-point positioning, anti-slip plug, use with GSGM support, support a variety of night vision instrument power supply.

3)The battery compartment can have four standard AA batteries No.5 simultaneously, from left to right 1.2.3.4, including No.1.2 is Group A, Group 3.4 is Group B, Group A and Group B are series structure, at least one battery in each group to operate normally and the output current, battery box output voltage is the sum of the highest single battery voltage in Group A and the highest single battery voltage in Group B, and the output voltage needs to be controlled between 2.0V-3.5V.

NOTE: Please use No. 5 standard AA battery, the battery voltage is between 1.2v-1.5v.

When purchasing, please pay attention to select the corresponding receiver

The L-type connector line is an upgraded line, so the price is a little expensive

L-shaped connecting wire:

4-pin aviation connector point-to-point positioning, anti-skid plug-in, suitable for connecting and supplying power between night instrument and video box (matching anpvs31 / gpnvg18 - BNVS)

Package Include :

1*Battery Box(only)+connector(excluding other products)
