Description

Model

1-6x24

Tube diameter

30mm(1.18in)

Magnification

1X-6X

ObjectiveLens Diameter

24mm

Eyepiece Field of view

20

Diopter range

+/-2

Exit Pupil Distance (mm)

96

Total travel elevation (@ 100 yds) (MOA)

100

Total travel windage (@ 100 yds) (MOA)

100

Parallax Compensation

100yds

Fast focus eyepiece

yes

Sealing gas used

Nitrogen

Clear aperture min magnification

15.552mm

Clear aperture max magnification

24mm

exit pupil diameter @min.magnification ± 3 %

15.6

exit pupil diameter @max.magnification ± 3 %

4.0

Maximum resolution in Arc. Second (min. Magnification)

11

Maximum resolution in Arc. Second (max. Magnification)

7

Range of Function temperature (Unit can still be operated)

-25°C/+55°C

Storage temperature

-40C to +85C

Range of Dioptric compensation +/- dpt

2

Permissible backlash Dioptric Compensation

<0.25dpt

objective field of view @ min magnification (ft @100yds)

109.2

objective field of view @ max magnification (ft@100yds)

18.2

Change of impact point after change of magnification(MOA)

1.5

Parallax of Reticle(minute

3

Centering Reticle, full Field of View

± 7 %

Straighteningof the Reticle

± 2 °

Trackout

<2'

Changing Line of Sight by switching Magnification from min. to max.

< 1.5 '

MOA per revolution tolerance

±0.75'

Coating

FMC

curvature of field of view

<1 dpt

distortion @ min / max magnification

<4%

straylight / Glare

< 2 %

Optical length at infinity and zero diopter

288mm
