Special Pie Shot Timers Shooting Timer for Competition Electronics M1A2-F Shot Timer , Rechargeable Tactical Electronic Earmuff

Thank you for choosing Special Pie tactical shooting gear. Reading the following instructions in detail can help you quickly understand and use this product

correctly.

1. Pay attention to distinguish the left and right earmuff (the audio monitor microphone facing forward), and use both hands to pull apart the earmuff on both sides with appropriate strength;

2. The headband of it is placed on the top of the head, and the two ears are completely placed in the cover of earmuff;

3. Adjust the length of the headband until it is comfortable to wear!

Instructions:
After wearing the earphones correctly, turn the "monitor switch and volume adjustment knob" with a clockwise rotation, then the earphone will be powered on after a click, and continue to turn the knob to adjust the monitoring volume from small to large.
Turn the "monitor switch and volume adjustment knob" by a counterclockwise rotation to adjust the monitor volume from high to low. After a click, the earmuff will power off and shut down.

Introduction to threshold value function of monitor:
The monitor function of this earphone incorporates a threshold value of automatic cut-off function for hearing protection. After the monitoring function is turned on, the threshold value function will be activated and the monitoring sound is automatically cut off if the ambient sound is greater than or equal to 82db; when the ambient sound is less than 82db, the threshold value function will be turned off and monitoring function is restored.

LINE-IN function
Instructions:

Use the 3.5mm audio cable to connect the earphone and your playback device to enter the LINE-IN working state.

(Automatically detect that the cable is plugged in and start working, you should unplug the cable after use to prevent the battery from running out)

Note:
1. Headphones cannot adjust the volume of LINE-IN;

Recharge
Instructions:

Use the included USB charging cable to charge for your earphone.
The red charging indicator means charging;
The green charging indicator means fully charged.

Shot timer

1.PROFILE

Shot timer is a device that responds to sound of gun shots, records the time that it occurs. They can give a start signal, usually a beep of some sort. M1A2 shot timer is suitable for military, police shooting training, IPSC, IDPA, 3GUNS and hunting sports. M1A2-FW is designed to improve your shooting skills. Whether you are law or military enforcement, competitive shooter or a hobby shooter .It is now widely used in military and police shooting training, professional shooting sports competitions in various regions and countries.

2.FUNCTIONS

Three in One function,It is not only a firearm shot timer and a stopwatch, and can also be used for countdown.

2.1Firearm Shot Timer

2.2Stopwatch

2.3Countdown

It is often used in walkthrough of stages before competition and the limited time event of shooting competition. The longest countdown time is 600 seconds.

3.FEATURES

3.1 Silicon buttons with working status indicator light.

The indicator light will guide user the next operation, visually see the working status of the device. Easier for shooters to operate.

3.2 Automatic backlight screen.

After hearing the gunshot, the screen will be light automatically. So the data showing on screen are clear to read, suitable for outdoor use under strong light conditions.

3.3 Automatic echo filtering.

Under closed indoor environment, interference filtering within a limited time is automatically eliminated to ensure accurate timing.

3.4 Quick access key.

When not in timing mode, press the unlock button for 2 seconds to quickly enter the sound and sensitivity adjustment page.

When not in timing mode, press the volume button for 2 seconds to quickly enter the interface for checking group scores.

When not in timing mode, press the "+" button for 2 seconds to quickly start/stop "PAR" mode.

When not in timing mode, press "-" button for 2 seconds to quickly begin countdown function.

3.5 Automatic shutdown.

Under power saving mode, you can customize the automatic shutdown time. When the device has been in non-operating state for your customized time, it will automatically shut down to save power.

3.6 Belt clip(Optional accessory)

When timer is clipped to a belt, it is easier for the shooter to move and view data. It can also be hung on the chest or backpack, easy to carry.

3.7 IPX4 Water Resistant

It can be used on rainy days at outdoor shooting events.

4.Versions

Bluetooth wired version: M1A2-FW

The Bluetooth timer can be connected with the Practiscore APP, which can assist RO to record the scores in shooting competitions.

In daily shooting training, it can help shooters to record the shooting results, analyze the shooting status and improve their shooting skills.

The Bluetooth shot timer can be connected with the LED display to show you shootings scord.

5.APPLICATION

5.1 Domestic military and police shooting training

5.2 2018 IPSC level 3 competition in Laos(RO uses it)

5.3 2020 IPSC Rifle level 3 competition in Ukraine

5.4 Used in lots of club’s shooting training and competitions all over the world.

6.Technical Parameters
